Rated output: 1.0kw.

Power supply voltage: AC200V

Same server motor SGMGH type.

Rated speed: 1000r/min

Power: 5.5kw.

Power voltage: three-phase AC200V. Serial encoder: 17 bit relative value

Design sequence: for machine tools.

Shaft end: straight shaft keyless SGDM-10ADA parameter setting tutorial Optional parts: with oil seal, DC24V brake.

High speed feed series: occasions where high-speed operation is also required when there is no load

Adopting a serial encoder, the number of encoder wiring is reduced by 1/2 compared to the original product.

Multi in one control: By using parameter switching, torque, position, and speed control can be used separately. Z-V series same server motor SGMGV type

Rated output: 7.5kw.

Power supply voltage: AC400V.

Serial encoder: 20 bit incremental type (standard).

Design sequence: Standard.

Shaft end: straight shaft, without keyway (standard) SGDM-10ADA parameter setting tutorial Optional: with oil seal, with holding brake (DC90V)
